Intel® Workstation Board S5520SC TPS Functional Architecture
Revision 1.7
Intel order number: E39530-010
37
3.4.1.1.1 Intel
®
Embedded Server RAID Technology II Option ROM
The Intel
®
Embedded Server RAID Technology II for SATA Option ROM provides a pre-operating system user interface for the Intel
®
Embedded Server RAID Technology II implementation and provides the ability to use an Intel
®
Embedded Server RAID Technology II
volume as a boot disk and detect any faults in the Intel
®
Embedded Server RAID Technology II volume(s).
3.4.1.2 Onboard SATA Storage Mode Matrix
Table 7. Onboard SATA Storage Mode Matrix
SW RAID = Intel® Embedded Server RAID Technology II (ESRTII)
Storage
Controller
Storage Mode* Description
RAID Types and Levels
Supported
Driver
RAID
Management
Software
RAID
Software
User’s Guide
Compatible
Backplane
Onboard SATA
Controller
(ICH10R)
Enhanced
6 SATA ports at
Native mode
N/A
Chipset driver or
Operating System
embedded
Broad OS Support
N/A N/A
AXX6DRV3GR,
AXX4DRV3GR
Compatibility
6 SATA ports: port 0,
1, 2, 3 at IDE Legacy
mode, port 4, 5 at
Native mode
N/A
Chipset driver or
Operating System
embedded
Broad OS Support
N/A N/A
AHCI
6 SATA ports using
the Advanced Host
Controller Interface
N/A
AHCI driver or
Operating System
embedded
Broad OS Support
N/A N/A
SW RAID 6 SATA Ports
SW RAID 0/1/10
standard
SW RAID 5 with
optional AXXRAKSW5
ESRTII Driver
Microsoft
Windows* and
selected Linux*
Versions only
Intel
®
RAID Web
Console 2
Intel
®
RAID
Software
User’s Guide
* Select in BIOS Setup: “SATA Mode” Option on Advanced | Mass Storage Controller Configuration Screen
